Secure SEC_SIR321 Z-Wave thermostat
Quickstart
This is a Central Controller for Europe.
To run this device please connect it to your mains power supply.
To add this device to your network execute the following action:
Press and hold the” pairing button on the unit until the RF LED starts” flashing at a fast rate. Then release the button.” On successful inclusion, the RF LED will stop flashing.
Please read this manual carefully. Failure to follow the recommendations in this manual may be dangerous or may violate the law. The manufacturer, importer, distributor and seller shall not be liable for any loss or damage resulting from failure to comply with the instructions in this manual or any other material. Use this equipment only for its intended purpose. Follow the disposal instructions. Do not dispose of electronic equipment or batteries in a fire or near open heat sources.
Z-Wave is the international wireless protocol for communication in the Smart Home. This device is suited for use in the region mentioned in the Quickstart section.
Z-Wave ensures a reliable communication by reconfirming every message (two-way communication) and every mains-powered node can act as a repeater for other nodes (meshed network) in case the receiver is not in direct wireless range of the transmitter.
This device and every other certified Z-Wave device can be used together with any other certified Z-Wave device regardless of brand and original long as both are suited for the same frequency range.
Product Description
Secure Intelligent Relay is having One relay, and support of duration base schedule, measuring of temperature and delta and interval temperature reporting etc
Prepare for Installation / Reset
Please read the user manual before installing the product.
In order to include (add) a Z-Wave device to a network it must be in factory default state. Please make sure to reset the device into factory default. You can do this by performing an Exclusion operation as described below in the manual. Every Z-Wave controller is able to perform this operation however it is recommended to use the primary controller of the previous network to make sure the very device is excluded properly from this network.
Safety Warning for Mains Powered Devices
ATTENTION: only authorized technicians under consideration of the country-specific installation guidelines/norms may do works with mains power. Prior to the assembly of the product, the voltage network has to be switched off and ensured against re-switching.
Installation
A means of disconnection from the supply, having at” least 3mm contact separation in both poles, must be” incorporated in the fixed wiring. We recommend a” separate fused circuit from the consumer unit (24-hour” supply) protected by a 15A HRC fuse or, preferably a” 16A MCB. In some cases immersion heater failure can” damage the SIR. Installation of a 100mA RCD will” provide additional protection for the unit. If the SIR is to” be connected to a ring main then the spur feeding the” controller should be protected in the same way. The SIR” is NOT suitable for mounting on an unearthed metal” surface.+
Unpack unit and remove front cover
Take the SIR out of its packaging and then remove the” front cover gently, using a slotted screwdriver in the” notch, as shown in the picture below:
Preparing SIR for surface wall mounting
SIR is suitable for mounting directly on to any surface” mounted single-gang moulded box having a minimum” depth of 25mm for UK, or 35mm for Continental” Europe. Cable entry can be made through the most” convenient cut-out.
Remove cut-outs before fixing the box. Where appropriate, drill the box to provide close-fitting entry for cables and heat-resistant flexible cords. Take care to remove sharp edges.” Ensure that the clamp is positioned the right way up i.e.” the projections on the underside of the clamp should” grip the cord in order to secure the cable firmly. The” cable clamp screws must be adequately tightened up to” 0.4Nm.
For flush wall mounting -” SIR can be mounted directly to any standard flush” mounting single-gang wiring box with a depth of 25mm” for UK (BS 4662), or 35mm for Continental Europe (DIN” 49073).
Clamp all surface wiring to the wall adjacent to the SIR,” using trunking where appropriate. The flexible cable to” the appliance should be passed through the cable entry” hole in the bottom edge of the SIR, and secured under” the cable clamp provided.”
Making connections
Use twin-and-earth cable with a maximum conductor” size of 2.5mm2 single conductor for the incoming supply” to the SIR. Use a suitably rated three-core flexible cable” to connect the SIR to the appliance to be switched. For” appliances rated up to 2kW use a minimum 1.0mm2 flexible conductors. For appliances rated up to 3kW use minimum of 1.5mm2 flexible conductors. Heat” resistant flexible cable must be used if connecting the” SIR to an immersion heater.
All un-insulated earth conductors must be sleeved and connected to the earth terminals on the back of the SIR.” The supply earth conductor and appliance earth” conductor must use the separate terminal connections” provided.” Switch off the mains supply and then connect the” conductors for the incoming supply and the appliance” on the back of the unit, as shown on the next page.” Connect the two leads from the optional external” temperature sensor probe (if supplied) to ‘H4’ and ‘1’” marked terminal. The probe wires do not have any” polarity.
Installing SIR on wall gang / flush wall box:
Carefully offer the SIR to the moulded/metal box and” secure using two screws. Take care not to damage the” insulation or trap the conductors when fitting to flush” wall box.”
Unit not signed on to network: RF LED slow flashing
RF inclusion/exclusion process: RF LED fast flashing
RF link lost to the controller: RF LED glow solid
RF network is OK: RF LED off
For optimum RF communication, fit the unit above floor” level, and at least 30cm away from metal objects and” appliances such as: microwave oven, cooker,” fridge/freezer, stainless steel sink,TV, set-top box” (satellite/cable/Freeview), radio or computer” (desktop/laptop/tablet).” Do not fit the unit within 100cm of RF devices, such as” DECT cordless phones or Wi-Fi routers.” It may be necessary to relocate the unit if problems with” communication occur.” Mobile phones should not be used or placed in the vicinity of this unit.
Fitting front cover and final check:
After fitting the mounting screws, fix the front cover” back on. Offer the front cover on to the unit and make” sure that it clicks securely in place.”
Inclusion/Exclusion
On factory default the device does not belong to any Z-Wave network. The device needs to be added to an existing wireless network to communicate with the devices of this network. This process is called Inclusion.
Devices can also be removed from a network. This process is called Exclusion. Both processes are initiated by the primary controller of the Z-Wave network. This controller is turned into exclusion respective inclusion mode. Inclusion and Exclusion is then performed doing a special manual action right on the device.
Inclusion
Press and hold the” pairing button on the unit until the RF LED starts” flashing at a fast rate. Then release the button.” On successful inclusion the RF LED will stop flashing.
Exclusion
Press and hold the” pairing button on the unit until the RF LED starts” flashing at a fast rate. Then release the button.” On successful inclusion the RF LED will stop flashing.
Node Information Frame
The Node Information Frame (NIF) is the business card of a Z-Wave device. It contains information about the device type and the technical capabilities. The inclusion and exclusion of the device is confirmed by sending out a Node Information Frame. Beside this it may be needed for certain network operations to send out a Node Information Frame. To issue a NIF execute the following action:
Press the Z-Wave Button
Quick troubleshooting
Here are a few hints for network installation if things dont work as expected.
- Make sure a device is in factory reset state before including. In doubt exclude before include.
- If inclusion still fails, check if both devices use the same frequency.
- Remove all dead devices from associations. Otherwise, you will see severe delays.
- Never use sleeping battery devices without a central controller.
- Dont poll FLIRS devices.
- Make sure to have enough mains-powered device to benefit from the meshing
Association – one device controls an other device
Z-Wave devices control other Z-Wave devices. The relationship between one device controlling another device is called association. In order to control a different device, the controlling device needs to maintain a list of devices that will receive controlling commands. These lists are called association groups and they are always related to certain events (e.g. button pressed, sensor triggers, …). In case the event happens all devices stored in the respective association group will receive the same wireless command, typically a ‘Basic Set’ Command.
Association Groups:
Group NumberMaximum NodesDescription
| 1 | 4 | Nodes to receive Schedule report |
| 2 | 4 | Nodes to receive multilevel sensor report”
Note: Group-2 is available only when external” temp sensor is connected.
|
Configuration Parameters
Z-Wave products are supposed to work out of the box after inclusion, however certain configurations can adapt the function better to user needs or unlock further enhanced features.
IMPORTANT: Controllers may only allow configuring signed values. In order to set values in the range 128 … 255 the value sent in the application shall be the desired value minus 256. For example: To set a parameter to 200 it may be needed to set a value of 200 minus 256 = minus 56. In case of a two-byte value the same logic applies Values greater than 32768 may needed to be given as negative values too.
Parameter 1: Enable Fail-safe timer
- Size: 1 Byte, D
- efault Value: 0
Setting Description
| 0 – 255 | Value |
Parameter 2: Temperature Scale
- Size: 1 Byte,
- Default Value: 0
Setting Description
| 0 – 127 | “°C |
| 128 – 255 | “°F |
Parameter 3: Temperature reporting intervals
- Size: 2 Byte,
- Default Value: 0
Setting Description
| 1 – 65534 | Seconds |
Parameter 4: Delta configuration temperature reporting
- Size: 2 Byte,
- Default Value: 0
Setting Description
| 1 – 100 | “°C in 0,1″°C |
| 1 – 500 | “°F in 0,1″°F |
Parameter 5: Temperature Cutoff
- Size: 2 Byte,
- Default Value: 0
Setting Description
| 1 – 1000 | “°C in 0,1″°C |
| 320 – 2120 | “°F in 0,1″°F |
Technical Data
| Dimensions | 85x85x44 mm |
| Weight | 123 gr |
| Hardware Platform | ZM3102 |
| EAN | 5015914083563 |
| IP Class | IP IP 20 |
| Voltage | 230 V |
| Load | 3000 W |
| Device Type | Central Controller |
| Generic Device Class | Binary Switch |
| Specific Device Class | Specific Device Class not used |
| Z-Wave Version | 4.53 |
| Certification ID | ZC08-14040014 |
| Z-Wave Product Id | 0x0059.0x0010.0x0002 |
| Frequency | Europe – 868,4 Mhz |
| Maximum transmission power | 5 mW |
Supported Command Classes
- Association
- Basic
- Configuration
- Manufacturer Specific
- Sensor Multilevel
- Schedule
- Switch Binary
- Version
Controlled Command Classes
- Basic
- Switch Binary
Explanation of Z-Wave-specific terms
- Controller — is a Z-Wave device with capabilities to manage the network.
Controllers are typically Gateways,Remote Controls or battery-operated wall controllers. - Slave — is a Z-Wave device without capabilities to manage the network.
Slaves can be sensors, actuators and even remote controls. - Primary Controller — is the central organizer of the network. It must be a controller. There can be only one primary controller in a Z-Wave network.
- Inclusion — is the process of adding new Z-Wave devices into a network.
- Exclusion — is the process of removing Z-Wave devices from the network.
- Association — is a control relationship between a controlling device and a controlled device.
- Wakeup Notification — is a special wireless message issued by a Z-Wave device to announces that is able to communicate.
- Node Information Frame — is a special wireless message issued by a Z-Wave device to announce its capabilities and functions.
