Zhilande TZ-803 Programmable Wifi Home Touch Screen Thermostat User Manual

Zhilande

Zhilande TZ-803 Programmable Wifi Home Touch Screen Thermostat

Zhilande-TZ-803-Programmable-Wifi-Home-Touch-Screen-Thermostat-Imgg

Specifications

  • Warranty: 1 Year
  • Temperature Setting Range Indoor: ±5-35℃
  • Overheat Protection Temperature: 75℃(Adjustable)
  • Power Supply Voltage: AC220V ±10% 50HZ/60HZ
  • Rating Load: 3000w
  • Equipment Temperature: 20-90℃
  • Temperature Control Accuracy:  5℃
  • Temperature Sensor: NTC
  • Antifreeze Temperature: 5℃
  • Brand: Zhilande

Introduction

The Zhilande TZ-803 Programmable Thermostat is an advanced heating and cooling control device designed to provide comfort and energy efficiency in residential and commercial environments. It offers programmable features that allow users to set specific temperature schedules throughout the day, ensuring optimal comfort while reducing energy consumption. The TZ-803 thermostat features a user-friendly interface with a backlit LCD screen for easy visibility and navigation. It offers a range of customizable settings and programming options, allowing users to create personalized temperature profiles based on their preferences and daily routines. This level of flexibility enables energy savings by adjusting the temperature according to occupancy patterns, thereby avoiding unnecessary heating or cooling when the space is unoccupied.

One of the key advantages of the Zhilande TZ-803 thermostat is its compatibility with a variety of heating and cooling systems, including gas, oil, electric, and heat pump systems. It supports both single-stage and multi-stage heating and cooling systems, making it suitable for a wide range of applications. Additionally, the TZ-803 thermostat incorporates advanced features such as adaptive intelligent recovery, which learns the heating and cooling characteristics of the space to optimize temperature control. It also offers vacation mode and temporary temperature override functions, providing additional convenience and flexibility.  Furthermore, the Zhilande TZ-803 thermostat supports Wi-Fi connectivity, allowing users to control and monitor their HVAC system remotely through a mobile app. This feature enables users to adjust temperature settings, monitor energy usage, and receive alerts or notifications, enhancing convenience and energy management capabilities.

What’s In the Box?

  • Zhilande TZ-803 Programmable Thermostat
  • Mounting Plate
  • Backplate
  • Screws and Anchors
  • User Manual

Features

The Zhilande TZ-803 Programmable Thermostat offers several features that contribute to its functionality and convenience. Here are some key features of the thermostat:

  1. Programmable Temperature Control: The thermostat allows you to create customized temperature schedules throughout the day. You can set different temperature levels for different times, optimizing comfort and energy efficiency based on your daily routine.
  2. Compatibility: The TZ-803 thermostat is compatible with a wide range of heating and cooling systems, including gas, oil, electric, and heat pump systems. It supports both single-stage and multi-stage systems, making it suitable for various applications.
  3. User-Friendly Interface: The thermostat features a user-friendly interface with a backlit LCD screen that provides clear visibility of temperature readings and settings. The interface is designed for easy navigation and programming.
  4. Adaptive Intelligent Recovery: This feature allows the thermostat to learn the heating and cooling characteristics of your space, adjusting the temperature accordingly. It ensures that your desired temperature is reached at the scheduled time, providing comfort while optimizing energy usage.
  5. Vacation Mode: The thermostat includes a vacation mode feature, which allows you to set a specific temperature while you are away for an extended period. This helps conserve energy during your absence.
  6. Temporary Temperature Override: If you want to temporarily override the programmed temperature settings, the thermostat allows you to adjust the temperature manually. It will revert to the programmed schedule at the next scheduled period.
  7. Wi-Fi Connectivity: The TZ-803 thermostat supports Wi-Fi connectivity, enabling remote access and control through a mobile app. You can adjust temperature settings, monitor energy usage, and receive notifications or alerts remotely, providing convenience and energy management capabilities.
  8. Energy Savings: By programming temperature schedules and utilizing features such as adaptive recovery, the thermostat helps you save energy and reduce utility costs by avoiding unnecessary heating or cooling when the space is unoccupied.
  9. Precise Temperature Control: The thermostat maintains precise temperature control within a specific range, ensuring optimal comfort in your space.
  10. Compatibility with External Sensors: Some models of the Zhilande TZ-803 thermostat may offer compatibility with external temperature and occupancy sensors, further enhancing the thermostat’s capabilities and control accuracy.

These features combine to provide efficient temperature control, energy savings, and user-friendly operation, making the Zhilande TZ-803 Programmable Thermostat a versatile and practical choice for residential and commercial heating and cooling systems.

How To Mount?

To mount the Zhilande TZ-803 Programmable Thermostat, follow these general steps:

  1. Turn off the power: Before starting the installation process, it’s essential to turn off the power supply to your heating and cooling system at the circuit breaker to ensure safety.
  2. Select a suitable location: Choose a location on an interior wall where the thermostat will provide accurate temperature readings and is easily accessible for programming and adjustments. Ensure that the location is away from direct sunlight, drafts, and other heat sources.
  3. Remove the existing thermostat (if applicable): If you’re replacing an existing thermostat, remove it from the wall by unscrewing it from its mounting plate. Take note of the wire connections and their corresponding labels.
  4. Mount the backplate: Hold the backplate against the wall and align it with the desired location. Use a level to ensure it is straight. Mark the mounting hole positions on the wall. Then, drill holes and insert the provided screws and anchors into the wall. Secure the backplate onto the wall by tightening the screws.
  5. Connect the wires: Connect the wires from your heating and cooling system to the corresponding terminals on the backplate of the thermostat. Follow the labeling on the backplate or refer to the user manual for guidance. Ensure that the connections are secure.
  6. Attach the thermostat: Carefully align the thermostat with the backplate and slide it into place. Apply gentle pressure until it snaps securely onto the backplate.
  7. Restore power and set up: Once the thermostat is mounted, restore power to your heating and cooling system by turning on the circuit breaker. The thermostat should power up, and you can proceed with the initial setup and programming by following the instructions provided in the user manual.

Frequently Asked Questions

How do I program the Zhilande TZ-803 thermostat?

To program the thermostat, navigate through the menu options using the interface and select the desired settings for each time period. Refer to the user manual for detailed instructions on programming specific temperature schedules.

Can I control the thermostat remotely?

Yes, the Zhilande TZ-803 thermostat supports Wi-Fi connectivity, allowing you to control and monitor it remotely through a mobile app. You can adjust temperature settings, view energy usage, and receive notifications or alerts.

Is the thermostat compatible with my heating and cooling system?
The TZ-803 thermostat is compatible with various heating and cooling systems, including gas, oil, electric, and heat pump systems. It supports both single-stage and multi-stage systems. However, it’s always recommended to check the thermostat’s compatibility with your specific system or consult the user manual for compatibility details.

Does the thermostat have a vacation mode?
Yes, the thermostat has a vacation mode feature that allows you to set a specific temperature while you are away for an extended period. This helps conserve energy during your absence.

Can I manually override the programmed temperature settings?
Yes, the thermostat allows you to manually adjust the temperature if you want to override the programmed settings temporarily. The thermostat will revert to the programmed schedule at the next scheduled period.

Does the thermostat have an adaptive intelligent recovery feature?
Yes, the TZ-803 thermostat incorporates adaptive intelligent recovery. It learns the heating and cooling characteristics of your space to optimize temperature control and ensure that the desired temperature is reached at the scheduled time.

How do I install the Zhilande TZ-803 thermostat?
Installation instructions can be found in the user manual. Generally, you will need to mount the backplate to the wall, connect the wiring from your heating and cooling system, and attach the thermostat to the backplate. It’s important to follow the provided guidelines and consult a professional if needed.

Can I use external sensors with the thermostat?
Some models of the Zhilande TZ-803 thermostat may offer compatibility with external temperature and occupancy sensors, providing additional control accuracy and functionality. Refer to the user manual or product specifications for details on sensor compatibility.
