Poer PTC10 WIRELESS Programmable Room Thermostat
SYMBOLS DESCRIPTION
PTC10/PTR10 is a wireless, programmable thermostat set that is easy to install and use. It can be applied to any water heating control system, including gas boilers, electric boilers, central heating systems, air heating systems. Suitable for installing new system or updating existed system.
Working together with Receiver PTR10, it not only wirelessly switch the heating system On and Off, also change and program the room temperature.
Connected to Internet with Gateway PTG10, this thermostat PTC10 could be operated remotely via App by mobile phone, PC or pad; Without gateway, thermostat PTC10 could be used as a normal standard thermostat.
Integrated with Amazon Alexa and Google Home
High and low temperature alarm message push notification.
Humidity display, more concerned about your room environment.
One PTR10 can connect two PTC10s for two independent zone control.
Gateway PTG10
As a bridge for smart homes, the gateway PTG10 provides an Internet access port for remote smart control of low-power smart products; it does not need a spare Ethernet port in the user’s home router just plug it into the e socket next to the wireless router.
PTC10 Features
| PTC10 Features: |
| 12 time periods per day, 5+2days/7days/1dayindependent programming for option |
| Auto , manual, holiday, ECO and override modes |
| Frost protection and Valve protection function |
| Memory holds user programs when power failed |
| Large LCD display with backlight |
| Battery powered with low battery indicator Child lock
I |
| Wall Mounted or Desk Stand to make sure the best location |
Connect to gas/electric boilers
Connect to electric actuators, zone valves and pumps
INSTRUCTION
- Receiver PTR16 working together with thermostat PTC10 can wirelessly control high-power heating equipment like electric heating and infrared heating, etc; also can control low-power AC devices like electric actuators, etc.
- By connecting to the Internet through the gateway PTG10, the temperature controller PTC10 can be programmed and adjusted the room temperature remotely by operating the app on the smartphone (supporting Android and IOS); without the gateway, the PTC10/PTR10 can still be used as left,d performance energy-saving wireless thermostat set.
- Integrated with Amazon Alexa and Google Home.
- Humidity display, more concerned about your room environment.
- High and low-temperature alarm message push notification.
- PTR16 can be connected to the external temperature sensor as a temperature limit function to prevent the fioor from overheating damage
Wireless WIFI thermostat PTC10
PTR10
Gateway PTG10
PTR16
Reference
Download Manual:
Poer PTC10 WIRELESS Programmable Room Thermostat Product Specification Guide
Other Manual:
Poer PTC10 WIRELESS Programmable Room Thermostat User Manual
Poer PTC10 WIRELESS Programmable Room Thermostat Product Specification Guide
