OCSTAT STN855 Touchscreen Programmable Thermostat
Introduction
The OCSTAT STN855 Touchscreen Programmable Thermostat is an advanced and user-friendly thermostat designed to provide precise temperature control and energy efficiency for residential and commercial environments. It combines the convenience of a touchscreen interface with programmable functionality, allowing users to easily set and adjust temperature settings according to their preferences and schedules. The STN855 thermostat features a sleek and modern design with a vibrant touchscreen display, making it intuitive and straightforward to operate. The touchscreen interface allows users to navigate through various settings and options effortlessly, providing a seamless user experience.
One of the key features of the OCSTAT STN855 is its programmable capabilities. Users can create customized schedules for different times of the day or week, ensuring optimal comfort and energy savings. By programming the thermostat to automatically adjust temperature settings based on occupancy patterns or specific time periods, users can efficiently manage their heating and cooling systems and reduce energy consumption when not needed. Additionally, the STN855 thermostat offers advanced features such as temperature calibration, vacation mode, and fan control options. Temperature calibration allows users to fine-tune the thermostat’s temperature readings for increased accuracy. The vacation mode enables users to set an energy-saving temperature while they are away, ensuring energy efficiency during extended periods of absence. The fan control options provide flexibility in managing the fan operation, allowing users to choose between automatic or continuous fan mode.
The OCSTAT STN855 Touchscreen Programmable Thermostat is compatible with a wide range of heating and cooling systems, including central air conditioning, heat pumps, and multi-stage systems. It supports both 24-volt and millivolt systems, making it suitable for various HVAC setups. The OCSTAT STN855 Touchscreen Programmable Thermostat offers a combination of sleek design, user-friendly interface, and advanced programmable features. With its precise temperature control and energy-efficient operation, it provides users with a comfortable and cost-effective solution for managing their heating and cooling systems.
Specification
- Model No.: STN855
- Programmability:7 Day, 5/1/1 Programmable or Non-programmable
- Temperature Range (˚F): 32˚F-99˚F (1°C-40°C)
- Control Temp.Range (˚F): 44˚F-90˚F (7°C-32°C)
- Temp.Meas.Accuracy: ±1°C (at 20°C)
- Power Source: DC 2 x AAA 1.5V Alkaline batteries
- 24VAC (18~30VAC), 50/60 Hz for hardwire (common wire)
- Dimensions: 120 x98 x28 mm
What Is In The Box
- Thermostat
- User Manual
- Screws
- External Senso
Features
- Up to 2 Heat, 2 Cool conventional
- Up to 3 Heat, 2 Cool Heat pump
- 7 Day, 5/1/1 programmable or Non-programmable
- Batteries or 24V power
- Large, easy to read clear LCD touchscreen
- Various backlight color options
- Auto Changeover
- Easy menu-driven programming
- Intuitive wake, leave, return, and sleep programming icons
- Electric or Gas configurable
- Separate heating and cooling swing (cycle rate) adjustments
- Keypad lockout
- Heating and cooling setpoint limit
- Filter change indicator (selectable on or off)
- Room temperature calibration adjustable
- 5-minute compressor delay protection (selectable on or off)
- Easy wire color-coded terminal blocks
- Universal sub-base
- Mounts on wall or junction box
- Contemporary design
- Factory pre-set program
Usage
- Installation: Follow the manufacturer’s instructions to install the thermostat properly. Ensure that the power supply is disconnected before installation.
- Powering on: Once installed, restore the power supply to the thermostat. The device will power on and display the home screen.
- Home screen: The home screen will show the current temperature, set temperature, and other relevant information. You can navigate through different menus and settings using the touchscreen interface.
- Adjusting temperature: To adjust the temperature, press the up or down arrow buttons on the touchscreen. The set temperature will be displayed, and the thermostat will adjust the heating or cooling accordingly.
- Programming schedules: The OCSTAT STN855 allows you to program schedules for different times of the day, allowing you to save energy and maintain comfort. To access the programming menu, navigate to the settings or schedule menu. Follow the on-screen instructions to set the desired temperature for different time periods.
- Mode selection: The thermostat offers different modes such as heating, cooling, auto, and off. Use the mode selection menu to choose the appropriate mode for your HVAC system.
- Fan control: You can also control the fan operation using the thermostat. Options typically include auto (fan runs as needed with the heating or cooling system) and on (fan runs continuously).
FAQS
What is OCSTAT STN855?
OCSTAT STN855 is a touchscreen programmable thermostat used for controlling and regulating temperature in residential or commercial settings.
How does OCSTAT STN855 work?
OCSTAT STN855 works by connecting to the heating, ventilation, and air conditioning (HVAC) system of a building. It allows users to set temperature schedules, adjust settings, and control the HVAC system through its touchscreen interface.
What are the main features of OCSTAT STN855?
The main features of OCSTAT STN855 include a touchscreen display, programmable temperature schedules, energy-saving modes, temperature calibration, humidity control, and compatibility with various HVAC systems.
Is OCSTAT STN855 compatible with all HVAC systems?
OCSTAT STN855 is designed to be compatible with most HVAC systems, including single-stage and multi-stage heating and cooling systems. However, it’s always recommended to check the compatibility with your specific HVAC system before purchasing.
Can OCSTAT STN855 be used in both residential and commercial buildings?
Yes, OCSTAT STN855 is suitable for use in both residential and commercial buildings. Its features and functionality make it suitable for a wide range of environments.
Does OCSTAT STN855 support Wi-Fi connectivity?
No, OCSTAT STN855 does not support Wi-Fi connectivity. It operates as a standalone programmable thermostat without internet connectivity.
How many temperature schedules can be programmed on OCSTAT STN855?
OCSTAT STN855 allows you to program up to four temperature schedules per day. This flexibility enables you to customize the temperature settings based on your daily routine.
Does OCSTAT STN855 have a backlight for the display?
Yes, OCSTAT STN855 features a backlight for the touchscreen display, allowing you to easily read and adjust the settings even in low-light conditions.
Can OCSTAT STN855 be controlled remotely?
No, OCSTAT STN855 does not have remote control capabilities. It requires manual interaction through its touchscreen interface.
Does OCSTAT STN855 have a built-in temperature sensor?
Yes, OCSTAT STN855 is equipped with a built-in temperature sensor to accurately measure the ambient temperature and provide precise temperature control.
What is the purpose of the energy-saving modes in OCSTAT STN855?
The energy-saving modes in OCSTAT STN855 allow you to optimize energy consumption by adjusting temperature settings when the building is unoccupied or during certain times of the day when lower or higher temperatures are desired.
Can OCSTAT STN855 display both Celsius and Fahrenheit temperature units?
Yes, OCSTAT STN855 provides the option to display temperature readings in both Celsius and Fahrenheit units, allowing you to choose your preferred unit of measurement.
Does OCSTAT STN855 have a battery backup?
Yes, OCSTAT STN855 is equipped with a battery backup that maintains its settings and keeps it operational during power outages.
Can OCSTAT STN855 control both heating and cooling systems?
Yes, OCSTAT STN855 is designed to control both heating and cooling systems, allowing you to maintain comfortable temperatures throughout the year.
Is the installation of OCSTAT STN855 complicated?
The complexity of installation may vary depending on your HVAC system and wiring setup. It’s recommended to consult the product’s installation manual or seek professional assistance to ensure proper installation and configuration of OCSTAT STN855.
