Neomitis RT7 RF Plus Wireless 7-Day Programmable Thermostat Pack Techinal Specification Guide

Neomitis RT7 RF Plus Wireless 7-Day Programmable Thermostat Pack

Benefits

• Dual optimization feature.
• Automation: flexible programming and easy modification to combine comfort and savings.
• Available in white (RT7RFPLUS) and also in black (RT7RFBPLUS).
• Quick and easy to install, with no cable to install, which means no decorative repair or flooring to disturb. Suitable for all heating applications.
• Large and easy-to-understand display.
• Easy to turn rotary control.
• Boost mode for immediate comfort.
• Energy savings from PID control.
• Reliable RF transmission is the ideal solution in home renovation: reliable, performance, and easy to install.
• Signal Strength Test Feature.
• Heating indication at the thermostat and RF receiver.
• RF receiver has a built-in temperature watchdog for additional frost protection.
• Service interval capable.
• Program lock.
• Load compensation.
• Automatic summer/winter changeover.

In a few words

This digital room thermostat has been designed for easy operation and is intended to make your life easier and help you save energy and money. The extra large LCD and ambient temperature digits mean that the display can be read from across the room and the simple rotary dial makes it perfect for everyone who wants a digital thermostat that is easy to understand. The slide control operation and simple programming method mean that everyone can set their own convenient schedule for each day of the week. Having the ability to customize each day of the week allows for greater efficiency savings. The dual optimization feature allows you to optimize your programming by favoring comfort or savings.
This digital thermostat is just one of a range of products that can provide the right solution for controlling your heating system in an easy and efficient way, whether it is a new installation or an improvement to an existing one.

Boiler Plus compliant features

Automation

• Single-day or multi-day programming.
• Programmable comfort periods.

Dual optimization
OPTI ECO or OPTI COMFORT, we design smart products to make your life easier. Optimize your programming by favoring comfort or savings: Depending on various parameters: room inertia, ambient temperature, and desired temperature, the thermostat calculates and optimizes the programming for each heating period whether set to Comfort or Savings (Eco):

• In OPTI ECO mode the thermostat’s inbuilt algorithm optimizes in order to guarantee maximum energy savings throughout the ECO program.
• In this mode, a slight drop in the temperature level at the beginning and end of the ECO period is allowed to maximize energy savings.
• In OPTI COMFORT mode the processor within the device starts the boiler operation at the optimum time to achieve the set point temperature at the start of the occupancy period without sacrificing comfort. The thermostat’s inbuilt algorithm optimizes in order to guarantee maximum energy savings throughout the COMFORT program.

Features

• White backlit display.
• Room temperature control.
• Operating modes: Auto, Comfort, Eco, Heating on Standby with frost protection.
• Boost function for 1 hour: temporary Comfort tempe-rature.
• Automatic summer/winter changeover.
• Program lock.
• Service interval function.
• Two choices of installation: Wall-mounted or on a table stand.

Technical specifications

White plastic housing RAL 9016. 2x AA (LR6) batteries supplied – 2 years typical life. Wall mounting plate and table stand supplied.

Type of control

• 2-point switching (ON/OFF).
• PID (Proportional Integral Derivative).
• Relay output on receiver: 5(2)A.

Radiofrequency: 2401.5MHz ~ 2477.5MHz. Environment

• IP30.
• Operating temperature: 0°C to +40°C.
• Setpoint temperature: +5°C to +30°C.
• Storage temperature: from -10°C to +60°C.
• Humidity: 80% at +25°C (without condensation).

Manufactured on ISO 9001 V2015 certified site. Standards

NEOMITIS® LIMITED – 4th Floor, Lincoln House, 300 High Holborn, London WC1V 7JH, UNITED KINGDOM – Registered in England and Wales No: 9543404
Tel: +44 (0) 2071 250 236 – Fax: +44 (0) 2071 250 267 – E-mail: [email protected] Pictures and technical specifications are not contractual and are given as an indication. Specifications may change depending on product development. Néomitis® keeps the right to change without notice. All rights reserved – Photo credits: © Fotolia

Neomitis RT7 RF Plus wireless 7-day programmable thermostat pack Technical Specification Guide
