Homematic eQ-3 Wireless Room Thermostat FEA

Homematic eQ-3 Wireless Room Thermostat Product Data Sheet

Homematic eQ-3 Wireless Room Thermostat

Homematic eQ-3 Wireless Room Thermostat PRO

PACKAGE CONTENTS

  • 1x Wireless Room Thermsotat
  • 2x 1.5 V LR03/micro/AAA batteries
  • Mounting material
  • (2 x adhesive strips, 2 x screws, 2 x plugs)
  • 1x Operating manual in DE and EN

FEATURES

  • Wireless room thermostat enables time-controlled regulation of room temperature in connection with one or more Homematic Wireless Radiator Thermostats (HM-CC-RT-DN)
  • The room thermostat measures the temperature and humidity and cyclically transmits the data to the radiator thermostat – the room temperature can be regulated precisely and quickly
  • Setpoint temperature in the room can be specified precisely (to the nearest 0,5°) via control wheel
  • Can be individually tailored to personal routines thanks to the freely programmable heating phases
  • Boost function for heating up the radiator quickly and briefly
  • Large display shows setpoint and actual temperature as well as humidity
  • Can be easily mounted with supplied adhesive strips
  • Integration into multi-gang frames or frames of other manufacturers (Berker, ELSO, Gira, merten, JUNG)
  • Electric radiators can be controlled via directly taught-in switch actuators

TECHNICAL SPECIFICATIONS

  • Supply voltage: 2x 1.5 V LR03/rnicro,’AAA
  • Battery life: 1 year (typ.)
  • Current consumption: 40 mA max.
  • Degree of protection: IP20
  • Dimensions (W x H x D)
  • Without frame: 55 x 55 x 20 mm
  • Including frame: 86 x 86 x 21.5 mm
  • Weight:  74 g (not incl. batteries)
  • Typical open area RF range: 300 m
  • Radio frequency: 868.3 MHz

LOGISTIC DATA

  • Product reference: 132030AO
  • EAN cnde: 4047976320301
  • Short description: HM-TC-IT-WM-W-EU
  • Packing unit: 90
  • Packaging dimensions: 122 x 112 x 48 mm
  • Total weight: 184 g

REFERENCE

DOWNLOAD MANUALS:

Homematic eQ-3 Wireless Room Thermostat Product Data Sheet

OTHER MANUALS:

Homematic eQ-3 Wireless Room Thermostat Installation And Operating Manual

Homematic eQ-3 Wireless Room Thermostat Product Data Sheet
